10.0m Superyacht Tender
The design brief was for Superyacht Tender to fit in the mother ship garage with maximum length of 10m and stowed height of 2.0m.
The boat has a sliding roof to walk thru, and bow door for easier beach landing.
Specifications
| Length Overall | 10.00m |
| Length (Waterline) | 9.42m |
| Beam Max | 3.16m |
| Draught (Mean) | 0.48m |
| Displacement | 5000kg |
| Engine | Volvo D6-370hp @ 3500 rpm |
| Drive | Volvo DPH Duoprop |
| Fuel | 250L |
| Fresh Water | 100L |
| Construction | E glass/Carbon composite/epoxy resin |
| Speed (Half load) | 35 Knots |
| Range | 200nm @ 28 Knots |
| Classification | CE Category: B Offshore |
