13.8m Power Boat Jokerman
Launched 2018
It was a great honour and pleasure to develop this design for a New Zealander sailor and yacht designer Murray Ross.
Specifications
| Length (hull) | 13.800m |
| Length (max) | 14.089m |
| Beam (hull) | 4.048m |
| Beam (max) | 4.086m |
| Waterline length | 12.191m |
| Waterline beam | 3.317m |
| Draft (half load) | 0.678m |
| Displacement (Half load) | 9570 Kgf |
| Cb | 0.341 |
| Weight to immerse 1.0cm | 295.7 Kgf/cm |
| Engines 570hp @ 3000RPM | 2x FPT N67 570 |
| Propulsion offset | ZT 280 Vertical |
| Drives deg. | 2x HJ292 @ 0 |
| Fuel | 1800L (2x 900L) |
